Helios RRK 180Ex Exproof Fan
32.856,57 TL
RRK 180 EX |
CENTRIFUGAL IN-LINE DUCT FAN 1 PH, EXPLOSION PROOF SPIGOT DIA. 180 MM |
Centrifugal fan specially designed to be installed in-line in circular ducting. Highly efficient backward curved centrifugal impeller made from polymers. Dynamially balanced to class G 6.3 DIN and ISO 1940 T.1. Totally enclosed, single phase condenser motor with low-noise, sealed for life ball bearings, tropical protection of windings, maintenance free and radio suppressed. |
Katolog için tıklayınız
Ref.no. | 5889 |
Model | RRK 180 EX |
Description | CENTRIFUGAL IN-LINE DUCT FAN 1 PH, EXPLOSION PROOF SPIGOT DIA. 180 MM |
Actual pressure | static |
Actual volume | |
Max.Vol. | 310 m³/h |
Speed | 2780 min-1 |
FLC un-controlled | 0.25 A |
STC un-controlled | 0.625 A |
Power | 50 W |
Voltage | 230 V / 1 ph / 50 Hz |
Schutzart IP | 54 |
Max. temp. | 50 °C |
Wiring diagram no. | 453 |
Weight | 3.85 kg |
Delivery time | Ex stock |
